Synaptotagmin 1 lumenal domain - 105 103CpH

Ca2+-sensor on synaptic vesicles, triggers neurotransmitter release
Polyclonal rabbit purified antibody
Cat. No.: 105 103CpH
Amount: 50 µg
Price: $475.00
Cat. No. 105 103CpH 50 µg specific antibody, lyophilized. Affinity purified with the immunogen, fluorescence-labeled with CypHer5E

CypHer5E is a pH-sensitive dye, fluorescent only after antibody internalization at the acidic pH of the lumen of the synaptic vesicle. CypHer5E can be detected with the filter sets for Cy5TM.

This product or portions thereof is manufactured under license from Carnegie Mellon University under U.S. Patent Application Number US 2006-0051758 and related patents. Cy, CyDye, and CypHer are trademarks of GE-Healthcare Ltd. Purchase of reagents related to the CypHer technology from Synaptic Systems GmbH provides a license for non-profit and in-house research use only. Any application of above mentioned technology for commercial purpose requires a separate license from GE-Healthcare Bio-Science Corp., 800 Centennial Avenue, Piscataway, NJ 08855-1327, USA.

. Albumin was added for stabilization. For reconstitution add 50 µl H2O to get a 1mg/ml solution in PBS. Either add 1:1 (v/v) glycerol, then aliquot and store at -20°C until use, or store aliquots at -80°C without additives.
Reconstitute immediately upon receipt! Avoid bright light when working with the antibody to minimize photo bleeching of the fluorescent dye.
Applications WB: N/A
IP: N/A
ICC: 1 : 100 up to 1 : 500 gallery
IHC: not tested yet
IHC-P/FFPE: not tested yet
Label CypHer5E
Immunogen Synthetic peptide corresponding to AA 1 to 8 from mouse Synaptotagmin1 (UniProt Id: P46096)
Reactivity Reacts with: rat (P21707), mouse (P46096).
Other species not tested yet.
For unknown reasons antibodies raised against the luminal N-terminus of Synaptotagmin 1 show a strong preference for the rat protein.
Specificity Specific for synaptotagmin 1, no cross-reactivity to synaptotagmin 2.
Matching control protein/peptide 105-10P
Remarks

This antibody is intended to be used for direct labeling of recycling synapses in primary neuronal cultures. The pH sensitive dye regaines its fluorescence after the reacidification of the synaptic vesicle lumen.

Data sheet 105_103cph.pdf
Cat. No.: 105 103CpH
Quantity: 50 µg
Price: $475.00
Background
Synaptotagmin 1 also known as p65, is an integral membrane glycoprotein of neuronal synaptic vesicles and secretory granules of neuroendocrine cells that is widely (but not ubiquitously) expressed in the central and peripheral nervous system. It has a variable N-terminal domain that is exposed to the lumen of the vesicle and a conserved cytoplasmic tail that contains two Ca2+-binding C2-domains.
Ca2+-binding to synaptotagmin triggers exocytosis of synaptic vesicles, thus linking Ca2+-influx during depolarization to neurotransmitter release.
Lumenal antibodies were used in living neurons to label synaptic vesicles from the outside via endocytotic uptake.
Protocols
