Synaptotagmin1 antibody luminal domain - 105 103AF

Synaptotagmin1 is a Ca2+-sensor on synaptic vesicles that triggers neurotransmitter release

pH-sensitive probe fluorescent only under acidic conditions

Rabbit polyclonal purified antibody
Cat. No.: 105 103AF
Amount: 50 µg
Price: $485.00
Cat. No. 105 103AF 50 µg specific antibody, lyophilized. Affinity purified with the immunogen, fluorescence-labeled with AcidiFluor Orange.

AcidiFluor Orange® is a pH-sensitive dye, fluorescent only after antibody internalization at the acidic pH of the lumen of the cellular compartment e.g. the synaptic vesicle.
It can be detected with established fluorescence detection systems.

AcidiFluor Orange: λex 570 nm / λem 590 nm

This product or portions thereof is manufactured under license from Tokyo University and is covered by Patents Application Number US 2010068733, US 20140248654, EP2098529A1/B1, JP WO 2013035767A, JP 5636080B2, WO 2008/0599910A1, WO 2016/1579937A1 and issued patents US 8258171 and US 9784732 and related patents. Acidifluor®, and Acidifluor Orange® and related products are trademarks of Goryo Chemical. Purchase of reagents related to the Acidifluor Series technology from Synaptic Systems GmbH provides a license for non-profit and in-house research use only. Any application of above mentioned technology for commercial purpose requires a separate license from: Goryo Chemical, EAREE Bldg., SF Kita 8 Nishi 18-35-100, Chuo-Ku, Sapporo, 060-0008 Japan.

Albumin was added for stabilization. For reconstitution add 50 µl H2O to get a 1mg/ml solution in PBS. Either add 1:1 (v/v) glycerol, then aliquot and store at -20°C until use, or store aliquots at -80°C without additives.
Reconstitute immediately upon receipt! Avoid bright light when working with the antibody to minimize photo bleeching of the fluorescent dye.
Applications

WB: N/A
IP: N/A
ICC: 1 : 100 up to 1 : 300 (see remarks) gallery
IHC: not tested yet
IHC-P: not tested yet
Label AcidiFluor Orange
Immunogen Synthetic peptide corresponding to AA 1 to 8 from mouse Synaptotagmin1 (UniProt Id: P46096)
Reactivity Reacts with: rat (P21707).
Other species not tested yet.
Matching control protein/peptide 105-10P
Remarks

ICC: This antibody is intended to be used for direct labeling of recycling synapses in primary neuronal cultures. The pH sensitive dye regaines its fluorescence after the reacidification of the synaptic vesicle lumen.

Data sheet 105_103af.pdf

References for Synaptotagmin1 - 105 103AF

Pulse-Chase Proteomics of the App Knockin Mouse Models of Alzheimer's Disease Reveals that Synaptic Dysfunction Originates in Presynaptic Terminals.
Hark TJ, Rao NR, Castillon C, Basta T, Smukowski S, Bao H, Upadhyay A, Bomba-Warczak E, Nomura T, O'Toole ET, Morgan GP, et al.
Cell systems (2020) : . 105 103AF IHC; tested species: mouse
Cat. No.: 105 103AF
Amount: 50 µg
Price: $485.00
Pulse-Chase Proteomics of the App Knockin Mouse Models of Alzheimer's Disease Reveals that Synaptic Dysfunction Originates in Presynaptic Terminals.
Hark TJ, Rao NR, Castillon C, Basta T, Smukowski S, Bao H, Upadhyay A, Bomba-Warczak E, Nomura T, O'Toole ET, Morgan GP, et al.
Cell systems (2020) : . 105 103AF IHC; tested species: mouse
Background

Synaptotagmin1, also known as p65, is an integral membrane glycoprotein of neuronal synaptic vesicles and secretory granules of neuroendocrine cells that is widely (but not ubiquitously) expressed in the central and peripheral nervous system. It has a variable N-terminal domain that is exposed to the lumen of the vesicle and a conserved cytoplasmic tail that contains two Ca2+-binding C2-domains.
Ca2+-binding to synaptotagmin triggers exocytosis of synaptic vesicles, thus linking Ca2+-influx during depolarization to neurotransmitter release.
Lumenal antibodies were used in living neurons to label synaptic vesicles from the outside via endocytotic uptake.
