Cat. No. 245 003CpH
|
50 µg specific antibody, lyophilized. Affinity purified with the immunogen, fluorescence-labeled with
CypHer5E.
CypHer5E® is a pH-sensitive dye, fluorescent only after antibody internalization at the acidic pH of the lumen of the synaptic vesicle. CypHer5E® can be detected with the filter sets for Cy5®.
CypHer5E®: λex 647 nm / λem 667 nm
This product or portions thereof is manufactured under license from Carnegie Mellon University under U.S. Patent Application Number US 2006-0051758 and related patents. Cy, CyDye, and CypHer are trademarks of GE-Healthcare Ltd. Purchase of reagents related to the CypHer technology from Synaptic Systems GmbH provides a license for non-profit and in-house research use only. Any application of above mentioned technology for commercial purpose requires a separate license from GE-Healthcare Bio-Science Corp., 800 Centennial Avenue, Piscataway, NJ 08855-1327, USA.
Albumin was added for stabilization. For reconstitution add 50 µl H2O to get a 1mg/ml solution in PBS. Either add 1:1 (v/v) glycerol, then aliquot and store at -20°C until use, or store aliquots at -80°C without additives. Reconstitute immediately upon receipt! Avoid bright light when working with the antibody to minimize photo bleeching of the fluorescent dye.
|
Applications
|
WB: N/A IP: N/A ICC: 1 : 200 up to 1 : 500 gallery IHC: not tested yet IHC-P: not tested yet
Western blot (WB); separation of proteins by PAGE and subsequent transfer to a membrane. Detection of target molecules is carried out with antibodies. Some antibodies require special sample preparation steps. For details, please refer to the “Remarks” section.
Immunoprecipitation (IP); Immunoisolation or pulldown of a target molecule using an antibody. For details and product specific hints, please refer to the ”Remarks” section.
Immunocytochemistry (ICC) on 4% PFA fixed cells. Immunoreactivity is usually revealed by fluorescence. Some antibodies require special fixation methods. For details, please refer to the “Remarks” section.
Immunohistochemistry (IHC) on 4% PFA perfusion fixed tissue with 24h PFA post fixation. Immunoreactivity is usually revealed by fluorescence or a chromogenic substrate. Some antibodies require special fixation methods or antigen retrieval steps. For details, please refer to the ”Remarks” section.
Immunohistochemistry (IHC-P) of formalin fixed, paraffin embedded (FFPE) tissue (some antibodies require special antigen retrieval steps, please refer to the ”Remarks” section). Immunoreactivity is usually revealed by fluorescence or a chromogenic substrate.
|
Label
|
CypHer5E
|
Immunogen
|
Synthetic peptide corresponding to AA 98 to 108 from human HA-tag
|
Specificity
|
Specific for HA-tag, hemaglutinin.
|
Matching control protein/peptide
|
245-0P
|
Remarks
|
This antibody is suitable for internalization studies when GFP is fused to an epitope residing in the lumen of an acidic compartment. The pH sensitive dye regaines its fluorescence after the acidification of the targeted cellular compartment.
|
