Cat. No. 105 011AbOR |
100 µg purified IgG, lyophilized, fluorescence-labeled with abberior STAR ORANGE.
abberior STAR® dyes have been especially developed for for Stimulated Emission Depletion (STED) microscopy which allows higher resolution imaging compared to confocal laser scanning microscopy. For many of the fluorescence labeled antibodies conjugated to abberior STAR® dyes established fluorescence detection systems can be used. This product or portions thereof is manufactured under license from abberior GmbH. Reconstitute immediately upon receipt! Avoid bright light when working with the antibody to minimize photo bleeching of the fluorescent dye. |
Applications |
Immunoprecipitation (IP); Immunoisolation or pulldown of a target molecule using an antibody. For details and product specific hints, please refer to the ”Remarks” section.', $event)" style="cursor: help;">IP: N/A Immunocytochemistry (ICC) on 4% PFA fixed cells. Immunoreactivity is usually revealed by fluorescence. Some antibodies require special fixation methods. For details, please refer to the “Remarks” section.', $event)" style="cursor: help;">ICC: 1 : 300 (see remarks) gallery Immunohistochemistry (IHC) on 4% PFA perfusion fixed tissue with 24h PFA post fixation. Immunoreactivity is usually revealed by fluorescence or a chromogenic substrate. Some antibodies require special fixation methods or antigen retrieval steps. For details, please refer to the ”Remarks” section.', $event)" style="cursor: help;">IHC: not tested yet Immunohistochemistry (IHC-P) of formalin fixed, paraffin embedded (FFPE) tissue (some antibodies require special antigen retrieval steps, please refer to the ”Remarks” section). Immunoreactivity is usually revealed by fluorescence or a chromogenic substrate.', $event)" style="cursor: help;">IHC-P: not tested yet Enzyme-linked immunosorbent assay (ELISA); a frequently employed method to quantify target-molecules in solution. The detection of some proteins requires special solubilization steps. For further information, please refer to the „Remarks“ section.', $event)" style="cursor: help;">ELISA: N/A |
Label | abberior STAR ORANGE |
Clone | 41.1 |
Subtype | IgG2a (κ light chain) |
Immunogen | Recombinant protein corresponding to AA 80 to 421 from rat Synaptotagmin1 (UniProt Id: P21707) |
Epitop |
Epitop: AA 150 to 240 from rat Synaptotagmin1 (UniProt Id: P21707) |
Reactivity |
Reacts with: human (P21579), rat (P21707), mouse (P46096), mammals, zebrafish. Other species not tested yet. |
Specificity | K.O. validated |
Remarks |
ICC: This antibody conjugate is especially suitable for high resolution STED microscopy. |
Data sheet | 105_011abor.pdf |
Synaptotagmin1, also known as p65, is an integral membrane glycoprotein of neuronal synaptic vesicles and secretory granules of neuroendocrine cells that is widely (but not ubiquitously) expressed in the central and peripheral nervous system. It has a variable N-terminal domain that is exposed to the lumen of the vesicle and a conserved cytoplasmic tail that contains two Ca2+-binding C2-domains.
Ca2+-binding to synaptotagmin triggers exocytosis of synaptic vesicles, thus linking Ca2+-influx during depolarization to neurotransmitter release.
Lumenal antibodies were used in living neurons to label synaptic vesicles from the outside via endocytotic uptake.
